Type:
Other
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
kintai
Model Number:
kts-400
Voltage:
AC220V 10% 50/60Hz, 220V / 50HZ
Current:
10A
Rated Capacity:
1kw
Rated Duty Cycle:
60%
Dimensions:
L805*W640*H750mm
Weight:
110kg
Usage:
Soldering
Certification:
ISO9001:2008
After-sales Service Provided:
Engineers available to service machinery overseas
Product name:
Automatic soldering robots,led soldering machine,soldering machine
Positioning:
CCD vision
Dispensing accuracy:
+/-0.015mm
X/Y/Z Working Range:
X400mm*Y400mm*Z100mm
XY/Z speed:
Max:800/500 (mm/s)
Motion /Drive System:
servo Motor + Ball Screw Driven
Memory Capacity:
1000 Programs - Unlimited (Data Storage via USB)
I/O Signals:
4 Inputs / 4Outputs ((extendable)
Patterns:
Dots, Line, Potting, Filling, Encapsulation, Sealing, Coating, Jetting
