4. Our Superiority is the Professionalism of our team.
- PCB And PCB Assembly For One-stop Service with Original Components According the BOM.
IC Imported from Digikey / Farnell etc.
- Low Cost with High Quality, Commitment of Quality Assurance.
- For 10 years Experience in PCB Field. ( Our Factory owns advanced
production equipment and experienced technical personnel. )
5. Detailed specification of manufaturing capacity:
|NO ||Item ||Craft Capacity |
|1 ||Layer ||1-30 Layers |
|2 ||Base Material for PCB ||FR4, CEM-1, TACONIC, Aluminium, High Tg Material, High Frequence ROGERS ,TEFLON, ARLON, Halogen-free Material |
|3 ||Rang of finish baords Thickness ||0.21-7.0mm |
|4 ||Max size of finish board ||900MM*900MM |
|5 ||Minimum Linewidth ||3mil (0.075mm) |
|6 ||Minimum Line space ||3mil (0.075mm) |
|7 ||Min space between pad to pad ||3mil (0.075mm) |
|8 ||Minimum hole diameter ||0.10 mm |
|9 ||Min bonding pad diameter ||10mil |
|10 ||Max proportion of drilling hole and board thickness ||1:12.5 |
|11 ||Minimum linewidth of Idents ||4mil |
|12 ||Min Height of Idents ||25mil |
|13 ||Finishing Treatment ||HASL (Tin-Lead Free), ENIG(Immersion Gold), Immersion Silver , Gold Plating (Flash Gold), OSP, etc. |
|14 ||Soldermask ||Green, White, Red, Yellow, Black, Blue, transparent photosensitive soldermask, Strippable soldermask. |
|15 ||Minimun thickness of soldermask ||10um |
|16 ||Color of silk-screen ||White, Black, Yellow ect. |
|17 ||E-Testing ||100% E-Testing (High Voltage Testing); Flying Probe Testing |
|18 ||Other test ||ImpedanceTesting,Resistance Testing, Microsection etc., |
|19 ||Date file format ||GERBER FILE and DRILLING FILE, PROTEL SERIES, PADS2000 SERIES, Powerpcb SERIES, ODB++ |
|20 ||Special technological requirement ||Blind & Buried Vias and High Thickness copper |
|21 ||Thickness of Copper ||0.5-14oz (18-490um) |
6. Quote Requirements for PCB and PCB Assembly project:
- Gerber File and Bom List;
- Quote Quantity;
- Advise your technical requirements for quoting reference;
- Clearly picturers of PCB or PCB Assembly Sample to us for reference;
- Test Mothod for PCB Assembly.
7. T-SOAR Factory Silhouette:
